Woodwork UK

katellwood

Lovely work, wold like too see more

katellwood

Have been wanting to post these for a while now, images of the completed flight https://i.imgur.com/0GMlmwC.jpg https://i.imgur.com/pIP987s.jpg https://i.imgur.com/8VbrqSe.jpg https://i.imgur.com/dFTQPdT.jpg https://i.imgur.com/804C0bs.jpg https://i.imgur.com/zBJH5jB.jpg https://i.imgur.com/q3No9Ld....

katellwood

https://www.workshopheaven.com/brass-y-lever.html

katellwood

Thanks for all the kind and encouraging comments its appreciated TNAF this may interest you, one I did last summer Was asked to quote for a new oak staircase. my first question was "are you going to carpet it" yes was the reply. I said "then you don't need a new staircase and this is what I did firs...

katellwood

Thought I would like to share the build of this flight of stairs This staircase and balustrade also acts as the support for the upper landing with the client wishing to maintain a view to some original leaded windows found in the property (which dates from the 18th century and was originally a pub/I...

katellwood

These may help

Plumb/foot cuts on both rafters and jack rafters are the same

katellwood

you would create a haunch in a wide tenon more to strengthen the mortice as in certain cases the mortice walls are thin and need bolstering in the middle this is purely subjective to the thickness of the material. In my case with six inch rails and 60mm+ thickness of material a central haunch in my ...

katellwood

Haunching is usually carried out on a corner joint say the top and bottom rail of a door so as to completely contain the tenon in the mortice, on wide rails (usually middle rails) the haunch is usually in the middle of the rail thereby preventing the need for an overlong mortice. The short tenon on ...

katellwood

bit of a wet day but just been out to take a few photo's https://i.imgur.com/5NjHUe9.jpg https://i.imgur.com/KcZlNsO.jpg absolutely no sagging of the gates or movement on the posts the only issue which does not concern me too much is that the auto closers needed to be place high up to so as to go ab...

katellwood

I would suggest you need a crosscut blade with chip limiters (this restricts how much material each tooth takes during the cut and prevent ride up)

katellwood

Rich

With a felder you will need a minimum of a chip extractor as the cutters will block up and seriously effect the timber finish. modern machines are designed to work with extraction as they throw all the spoil in the direction of a 100/125mm pipe

katellwood

Hi You would not go far wrong with this (or something like) at the right price https://www.ebay.co.uk/itm/FELDER-BF6-26-Combination-Woodworking-Machine-on-360-degree-turntable-240-v/273681270438?hash=item3fb8acc6a6:g:G~gAAOSw7C5cVDNl:rk:1:pf:1&frcectupt;=true I'm on my third combi the last two being ...

katellwood

oxalic acid powder (which you dissolve in warm water) or liberon wood bleacher (which is prepared oxalic acid)

katellwood

Glad to be of help.

Its good that we can all learn from each other, its what forums are for

katellwood

just my two penneth If you are cutting full sized sheets (8 x 4) on a £400 table saw you are going to struggle and the initial cuts will not be very accurate. I also use a Felder with a sliding table however for the initial cuts I start with a dewalt track saw and a 2.7m track. Its far easier to car...

katellwood

Thanks for the link to that thread which I missed first time round. I'm going to look forward to reading that. It's a good tip but had you thought of a power feeder on your planer ? This is mine with a 4.4m length of timber being prepped for skirting. (bottom LH corner) https://farm5.staticflickr.c...

katellwood

I'm on my third combination machine and my second Felder and whilst I can see the point of some of the above comments and essentially agree I run a combi due to workshop size That being said and being a one man band one advantage I have exploited is the use of a long sliding table with the spindle. ...

katellwood

Wax polish works for me, also keeps them slick

katellwood

https://www.axminster.co.uk/axcaliber-d ... ant-503468

katellwood

this picture may help https://i.imgur.com/MGJbbdT.jpg Because the cutter is further away from the centre line of the block when the cutter is 90 degrees to the fence then when it hits the timber it hits it at more of an acute angle so for example if cutting a quarter round then in height from the be...

katellwood

One final thing, because the cutter is mounted further away from the centre than modern pinned blocks the shape of the cutter will not be the same as the moulding produced

katellwood

don't want to teach you how to suck eggs however if you have not used these blocks before a couple of tips if I may. I assume you are using a pair of cutters, balance is important with these blocks so getting the two cutters in place accurately is important. I use an L shaped ply slip drawing around...

katellwood

they appear on ebay from time to time (i think you just missed one) however if you want I could lend you one (believe you are in Kent)

katellwood

Try cleaning it off with some oxalic acid diluted with warm water, that should get rid of any black marks and revive the timber.

You then need to neutralise with water, let it dry and cut back the raised grain prior to finishing

katellwood

An update too this. I appreciate there has been a delay in getting these swinging, the main reason being I spent the majority of the winter in Australia and if I had hung them prior to going I would not have been able to monitor any movement in the boards and take any remedial action as needed. Anyw...

katellwood

This is the only cost effective way of replicating square balusters I know of, however pretty specialist

https://www.instagram.com/p/BQ0COylguCq ... d=therming

You could try Richard Findley

katellwood

Thanks for all the nice comments/constructive criticisms and advice, its all very much appreciated. Where we are at the moment is, I have had delivered two pair of 900mm adjustable hooks and bands. They were advertised as being galvanised and powder coated however the coating was flaking a little (d...

katellwood

Have been to JW timber a few times, unfortunately they no longer supply AW oak just European, however for service I cannot fault them. The last lot of Oak I bought(What i built the gates from here http://www.woodworkuk.co.uk/forum/viewtopic.php?f=9&t;=13444) was from http://oakandwood.co.uk/ They do ...

katellwood

Aren't Timbmet now owned by Meyers??? There used to be a Meyers close to me in Strood, Kent, that closed. I then started using Timbmet in Larkfield, Kent and on being taken over they closed that branch. Being a one man band with limited storage I only collect materials, don't have anything large del...

katellwood

davidpidge wrote:Fantastic WIP photos. They are some monster bits of joinery! How are you moving them around?

I'm not at the moment. they were just about manageable prior to boarding however now boarded I need someone to help me move them about.

katellwood

Very impressive matey. The only thing I would be concerned with is the expansion gap between the boards. From personal experience I don’t think that 1.5mm will be enough - I’d have gone for 3mm and treated them before assembly. I hope I’m wrong as they really do look the business. Yes that's someth...

katellwood

Driveway Gates I’ve just completed a pair of driveway gates. These are for myself and are part of a long ongoing project whereby I have created a new driveway. This has included digging out a few tons of earth, laying brick retaining walls which included elements of curved brickwork, laying approx 1...

katellwood

Stenner Band-Re-saw would cut through this in about one minute your Bandsaw 20+ I'd say.............? Stenners I've seen approx 10-20 secs for an 8' length my setup 2-3 mins 2-3 minutes is Much quicker than I thought. Perhaps I should buy some blades like you as I have some odd blocks of oak that I...

katellwood

hope this helps

katellwood

Nearly right, its this one http://www.ikea.com/gb/en/products/lighting/work-lamps/jansj%C3%B6-led-work-lamp-black-art-00169659/ I've replaced the supplied weighted base with a piece of timber and super-glued two 25mm rare earth magnets into the new base. Works a treat and rock solid, stays where you...

katellwood

The attached was resawing kiln dried 6" and 8" euro oak 8' long. the machine is a Meber 500 with a approx 20" throat and 12" depth of cut, single phase with a 2hp motor. https://i.imgur.com/JrdsWth.jpg As you can see I used supports both front and rear which are essential for this type of cutting (...

katellwood

The attached was resawing kiln dried 6" and 8" euro oak 8' long. the machine is a Meber 500 with a approx 20" throat and 12" depth of cut, single phase with a 2hp motor. https://i.imgur.com/JrdsWth.jpg As you can see I used supports both front and rear which are essential for this type of cutting (e...

katellwood

How about, "gun-stop joint" , that's a pearl for you. It's a diminishing joint in the middle rail/stile of a door. Levelle r is the man to explain the joint to you, but he has not yet entered this thread. Mark In the absence of leveller and if I may, its actually known as a gunstock stile (as the s...

katellwood

I've used both PU and Titebond 3 on iroko worktops successfully.

One suggestion is to wipe the joints with thinners then let it evaporate prior to gluing, this should remove any oils contained in the timber which could affect the adhesives abilities

katellwood

PM sent
